Minimalist sliding with RPT, designed especially for large frames in response to new architectural trends that seek to combine maximum transparency with the minimum view of profiles.
Its innate rolling system with multiple bearings integrated into the lower frame allows weights per leaf of up to 800 kilos with motorized opening, being recommended for manual openings not to exceed 350 kilos per leaf.
This system has frames with one, two, three or more lanes allowing the creation of large openings such as passage to terrace or porch. Minimalist front central leaf profile of 30 mm visible front, an identity that provides the system with open spaces with a greater visual field.
Closing the sash with the frame is carried out using a multi-point security system activated by a lever.
Wide range of profiles, which facilitate the composition of different designs as well as multiple possibilities in their implementation; open corner solution, hiding leaves within the factory wall and fences integrated into the floor completely hidden, multiple lanes to accommodate the number of leaves required by the project.
Maximum glazing rebate of 38 mm.
It marks the line of excellence in the range of sliding openings with a minimal aluminium profile for large glass dimensions.
POSSIBILITY OF DIFFERENT FINISHES
-
Bicolor
-
Lacquered Color (RAL, mottled and rough)
-
Sublichrome Lacquered Wood
-
EZY® Wood Lacquer
-
Antibacterial Lacquer
-
Anodized
Characteristics
-
Minimalist sliding carpentry
-
Frame section: 156mm
-
Side sheet section: 59 x 52 mm
-
Thermal bridge break with
-
18 mm polyamide in frames
-
28 mm polyamide in sheets
-
-
Manual opening with a recommended weight per leaf up to 400 kilos
-
Motorized opening with a maximum weight per leaf up to 800 kilos
-
Locking with interior and exterior key.
-
Maximum glazing up to 38 mm
-
Opening possibilities:
-
Slide
-
Corner meetings at 90º without mullion
-
Galandage
-
Hidden Hearth
-
